Shacman 380hp Dump Truck
Model: SX3258DR384、SX3255DR384、SX3255DT384
F3000 spacious and bright cab, within air seat, technology sense design makes driving safer
Engine: Weichai Or Cummins is optional, with displacements from 6L to 13L and power from 180-560 horsepower
Gearbox: Famous brand Fast, 9,10 and 12 gears optional to meet different needs
Introduced in 2009, the F3000 series the one of the best selling product. Reliable, rugged and powerful, the F3000 series can tackle any task its owner ask of it.
Product Details
Shacman F3000 dump truck adopt Gemeny Man Axles, dependable, rugged and powerful, the f3000 series can address any venture its proprietor ask of it.
Specification
F3000 6×4 dump truck | ||
Weight Parameter | Curb mass(kg) | 12500 |
Full loaded mass(kg) | 40000 | |
Wheel Base(mm) | 3800+1350 | |
Cabin | Four-point hydraulic suspension cab | |
Engine | Model | WEI CHAI , WP10.336E53 Euro Ⅴ、WP10.340E22 Euro II、WP10.380E22 Euro II WP12.375N Euro III |
Horsepower | 340/380/430 | |
Type | water-cooled, turbo-charged & inter-cooled, direct injection | |
Transmission | Model | 10JSD180/12JSD200 |
Front Axle | Type | MAN 9.5T |
Rear Axle | Type | 16T MAN Two-stage 5.262、16T MAN Two-stage 5.92、16T MAN Two-stage 5.262 |
Cargo | Carriage Internal Dimensions(mm) | (5200-6000)*2300*1500 |
Steel | Q255, Q355, T700,H800, NM450 etc. | |
Cubage(m³) | 16~25 | |
Steel thickness of Carriage(mm) | Floor:8mm/ Side:6mm | |
Can be customized according to usage | ||
Performance Parameter | Max.Speed (km/h) | 90 |
Economic Speed(km/h) | 65~80 | |
Tire | 12.00R20,295/80R22.5,12R22.5 | |
Details
Upgraded Bumper
The bumper is made of 5mm thick steel plate for armor like protection. The headlamp is embedded within the steel plate bumper for easy maintenance. The reinforced headlamp protective grid is matched to reduce the risk of headlamp being damaged by debris in bad road conditions.
Strebgthened Suspension
The diameter of the U-bolt of the front leaf spring is upgraded to the thickest in the industry, up to 20 mm, which can improve the strength of the leaf spring bolt, reduce the fracture failure, and adapt to the bad working conditions. Strengthen the rear leaf spring improves the vehicle carrying capacity, which is suitable for overload transportation and bad road conditions in mining area.
Oil Pan Protector
The enhanced oil pan protection completely covers the water tank and engine oil pan, which improves the strength and the adaptability of the vehicle under bad road conditions.
Newly Desined Fuel Tank
400L standard liter flat iron tank is fixed with three widened tension belts to effectively prevent tank shaking and reduce failure. The lower part of the fuel tank is equipped with a 3mm steel plate protection guard, which can effectively protect the fuel tank from debris on the ground. The ground clearance of the super edition F3000 dump truck fuel tank is 590 mm above the ground.
Redesigned Tall Lamp
In order to adapt to the bad road conditions, a new design of rear tail lamp is made. The tail lamp bracket adopts a thick and solid integral structure to reduce the risk of fracture. It is equipped with full LED tail lamp to extend the service life of the tail lamp.
Battery Box Protection
The battery box protection has the function of anti-theft and is impact resistant, to prevent theft, flying stones and other debris from damaging the battery box.
Shipping
We usually adopt shipping by bulk cargo, flat rack, and Roro ship. We will arrange the most cost-effective transportation mode according to the quantity of products. All trucks will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
Delivery time:20-40 working days after payment receipt confirmed (based on actual quantity).
Packing:Standard export packing, or customized packing as your request.
Professional goods shipping forwarder.
After-sales Service
1.12months or 100,000km for main parts (engine, axle, body and beam, etc).
2.Technical Support by phone Whatsapp or email around the clock.
3.Lifelong Parts Supports.
4. Engineer available service oversea.
FAQ
Q1. Are you a manufacturer?
Yes, we have been in special vehicle manufacturing and marketing for over 25 years.
Q2. What markets do your vehicle export to?
Europe, North & South America, South-East Asia, Africa, Oceanica, Middle East countries etc.
Q3. What information should I let you know if I want to get a quotation?
Please let us know your purpose, road condition, cargo type, tons of your cargo, dimensions of the trailer, quantity etc. The more info you provide, the more accurate model and the price you will get.
Q4. Is it available to print our own brand on the vehicle?
Totally acceptable as you wish.
Q5. How can I get the price of your vehicle?
You can connect with us through any contact information. Our personalized service person will respond to you within 24 hours.
